DIMONDS® S1804MB/B1 Blend Polyols for Spray Foam Modular Buildings System

Short Description:

Description DIMONDS® S1804MB/B1 is a two-components, spray-applied, closed-cell polyurethane foam system. It’s premixed polyols with HFC-245fa as foaming agent, which is specialized designed for modular building insulation systems which has higher requirement for fire resistance. Characteristic of DIMONDS SPF for MBS Developed low odor foam system to solve the MB smell issues to improve living comfort . Foam performances meet requirement of standard ASTM C1029-20 Type II. Meets the high f...

FOB Price: US $2.0 - 4.0/Kg

Min.Order Quantity: 1000 Kg

Supply Ability: 1000 MT per Month

Send email to us Download as PDF

Product Detail

Product Tags

Description

DIMONDS^® S1804MB/B1 is a two-components, spray-applied, closed-cell polyurethane foam system. It’s premixed polyols with HFC-245fa as foaming agent, which is specialized designed for modular building insulation systems which has higher requirement for fire resistance.

Characteristic of DIMONDS SPF for MBS

Developed low odor foam system to solve the MB smell issues to improve living comfort .
Foam performances meet requirement of standard ASTM C1029-20 Type II.
Meets the high fire test standard ISO 5660 specialized designed for buildings over 10 meters.

Typical Properties

Item	Unit	DIMONDS^® S1804MB/B1	DIMONDS^® ISO1800
Physical state	By visual	Transparent liquid	Brown liquid
Viscosity, 25℃	mpa.s	200-400	150-250
Gravity,20℃	g/ml	1.15±0.1	1.24±0.01
Packing	Kg/drum	220	250

Reaction properties (hand test)

Item	Unit	Specification
Cream time	sec	2-6
Gel time	sec	8-20
Free rise density	kg/m3	≥35

Recommended processing information

Item	Unit	Specification
Hose heat temperature	℃	35-55
Primary heat temperature	℃	35-55
Static pressure	psi	1100-1600
Dynamic pressure	psi	1000 min
Ambient temperature	℃	-5-50

Foam properties

Item	Unit	Specification	Test standard
Core density	kg/m3	≥45	ASTM D1622-08
Thermal conductivity, 20℃	W/(m.k)	≤0.023	ASTM C518-10
Compressive strength	kPa	≥200	ASTM D1621-10
Closed cell content	%	≥93	ASTM D6226
Water absorption	%	≤3	ASTM C209-12
Dimension stability, -30-80℃	%	≤3	ASTM D2126-09
Flammability	/	B1	DIN 4102

The above testing data have been generated in lab or field conditions which are typical for this application. They are believed to be correct but data variations due to varying processing or ambient conditions can not be excluded. The customer remains responsible for making his own interpretation of data and suitability of the chemicals to his particular operation.

Handling and Storage

DIMONDS^® S1804MB/B1 should be protected from moisture by keeping containers sealed when not in use. Drums have to be stored indoors to protect the material from water ingress, frost and direct heat from the sun. Under temperature conditions and in properly sealed containers ,the storage life of the polyol is 6 months for Polyol and 12 months for Isocyanate. The optimum storage temperature should be 10-25℃.

Packing

220kg/drum for DIMONDS^® S1804MB/B1 and 250kg/drum for DIMONDS^® ISO1800.
