DIMONDS® S1804LNG Blend Polyols for Spray Foam LNG Cryogenic Insulation

Short Description:

Description DIMONDS® S1804LNG is a two-components, spray-applied, closed-cell polyurethane foam system. This product is premixed with HFC-245fa as foaming agent which designed specializing for cryogenic insulation engineering, such as tanks and large-scale pipelines etc. Typical Properties Item Unit DIMONDS® S1804LNG DIMONDS® ISO1800 Physical state By visual Transparent liquid Brown liquid Viscosity, 25℃ mpa.s 200-500 150-250 Gravity,20℃ g/ml 1.15±0.1 1.24±0.01 Reaction properties...

FOB Price: US $2.0 - 4.0/Kg

Min.Order Quantity: 1000 Kg

Supply Ability: 1000 MT per Month

Send email to us Download as PDF

Product Detail

Product Tags

Description

DIMONDS^® S1804LNG is a two-components, spray-applied, closed-cell polyurethane foam system. This product is premixed with HFC-245fa as foaming agent which designed specializing for cryogenic insulation engineering, such as tanks and large-scale pipelines etc.

Typical Properties

Item	Unit	DIMONDS^® S1804LNG	DIMONDS^® ISO1800
Physical state	By visual	Transparent liquid	Brown liquid
Viscosity, 25℃	mpa.s	200-500	150-250
Gravity,20℃	g/ml	1.15±0.1	1.24±0.01

Reaction properties (hand test)

Item	Unit	Specification
Cream time	sec	3-6
Gel time	sec	10-20

Recommended processing information

Item	Unit	Specification
Hose heat temperature	℃	35-55
Static pressure	psi	1200-1600
Dynamic pressure	psi	1100 min
Ambient temperature	℃	-5-50
Ambient humidity RH	%	≤70

Foam properties

Item	Unit	Specification	Test standard
Core density	kg/m3	≥40	ASTM D1622-08
Thermal conductivity, 20℃	W/(m.k)	≤0.023	ASTM C518-10
Tensile strength	kPa	≥210	ISO 1926:2009
Compressive strength	kPa	≥180	ASTM D1621-10
Cohesion	kPa	≥210	ASTM D1623-17
Closed cell content	%	≥90	ASTM D6226
Liner thermal expansion coefficient	μm/(m·℃)	≤-100	ASTM E831-14
Thermal stability-30, 24h-RT,2h-70℃,90%RH, 24h	%	≤1.5	ASTM D2126-09
Flammability		B1/B2	DIN 4102

The above testing data have been generated in lab or field conditions which are typical for this application. They are believed to be correct but data variations due to varying processing or ambient conditions can not be excluded. The customer remains responsible for making his own interpretation of data and suitability of the chemicals to his particular operation.

Handling and Storage

DIMONDS^® S1804LNG should be protected from moisture by keeping containers sealed when not in use. Drums have to be stored indoors to protect the material from water ingress, frost and direct heat from the sun. Under temperature conditions and in properly sealed containers ,the storage life of the polyol is 6 months and Isocyanate 12 months.

The optimum storage temperature should be 10-25℃.

Package

220kg/drum for DIMONDS^® S1804LNG and 250kg/drum for DIMONDS^® ISO1800.
