DIMONDS® P1822 Blend Polyols for PUR Foam Continuous Sandwich Panel

Short Description:

Description DIMONDS® P1822 is a PUR-rigid foam system for continuous panel with an insulation of thickness of 40-200mm. Suitability must be examined by the user prior to commercial use. We can provide 2 components or 4 components as your requirement. Typical Properties Item Unit DIMONDS® P1822 DIMONDS® ISO1800 Physical state By visual Transparent liquid Brown liquid Viscosity, 25℃ mpa.s 400-600 150-250 Gravity,20℃ g/ml 1.20±0.05 1.24±0.01 Reaction Properties (hand test) Item U...

FOB Price: US $2.0 - 4.0/Kg

Min.Order Quantity: 1000 Kg

Supply Ability: 1000 MT per Month

Send email to us Download as PDF

Product Detail

Product Tags

Description

DIMONDS^® P1822 is a PUR-rigid foam system for continuous panel with an insulation of thickness of 40-200mm. Suitability must be examined by the user prior to commercial use. We can provide 2 components or 4 components as your requirement.

Typical Properties

Item	Unit	DIMONDS^® P1822	DIMONDS^® ISO1800
Physical state	By visual	Transparent liquid	Brown liquid
Viscosity, 25℃	mpa.s	400-600	150-250
Gravity,20℃	g/ml	1.20±0.05	1.24±0.01

Reaction Properties (hand test)

Item	Unit	Specification
Cream time	sec	10-20
Gel time	sec	35-65
Free rise density	kg/m3	30-36

Processing Temperature

Component temperature	℃	22±3
Temperature of facing layers	℃	35±3
Temperature of double belt laminator	℃	45±5
Dynamic pressure	kPa	130±10

It is recommended to utilize high pressure foaming machinery. The chemicals should be adjusted to the correct temperature between 20-24℃ to ensure reactivity and viscosity suitable for processing. The mixing pressure has to be set for both components at 120-140 bar.

Foam Properties

Item	Unit	Specification	Test standard
Core density	kg/m3	≥37	ASTM D1622-08
Thermal conductivity, 20℃	W/(m.k)	≤0.021	ASTM C518-10
Compressive strength	kPa	≥140	ASTM D1621-10
Thermal stability, -30-80℃	%	≤1.5	ASTM D2126-09
Flammability	/	B3	DIN 4102

The above testing data have been generated in lab or field conditions which are typical for this application. They are believed to be correct but data variations due to varying processing or ambient conditions can not be excluded. The customer remains responsible for making his own interpretation of data and suitability of the chemicals to his particular operation.

Handling and Storage

DIMONDS^® P1822 should be protected from moisture by keeping containers sealed when not in use. Drums have to be stored indoors to protect the material from water ingress, frost and direct heat from the sun. Under temperature conditions and in properly sealed containers ,the storage life of the polyol is 6 months and 12months for Isocyanate.

The optimum storage temperature should be 10-30℃.

Package

220kg/drum or 1000kg/IBC for DIMONDS^® P1822.

250kg/drum or 1250kg/IBC for DIMONDS^® ISO1800.
